Height Adjustment	One-touch Spline Controller
Adjustment Increments	Minimum 0.1 mm step
Usages	Plate & Pipe's beveling for weld preparation
Maximum Bevel range per angle	0° ~ 90°
	Deg.	Thickness (inch)	Width (inch)
	0°	14mm (0.551)	4mm(0.157)
	15°	14.5mm (0.570)	15.5mm (0.610)
	30°	8.3mm (0.326)	9.6 (0.378)
	45°	6mm (0.236)	8.5 (0.334)
	75°	1.6mm (0.062)	6mm (0.236)
	90°	5mm (0.196)	6.4mm (0.252)
Pipe Size	minimum 50A (60.5 mm or 2") or bigger
Pipe roller device	15A[21.7mm or 1/2"]~ 80A[89.1mm or 3"]
Weight	3.2kg
Power	850W
Inserts	3EA
	CFWB080360
Applications	Steel (carbon & stainless steel, etc.), Non-ferrous metal, other materials
