Height Adjustment	One-touch Spline Controller
Adjustment Increments	Minimum 0.1 mm step
Usages	Pipe & Plate's beveling for weld preparation
Maximum bevel range per angle	0° ~ 90 °
	Deg.	Thickness (inch)	Width (inch)
	0 °	27 mm (1.063)	11.5 mm (0.453)
	15 °	28 mm (1.102)	29 mm (1.142)
	30 °	23 mm (0.905)	26.5 mm (1.043)
	45 °	15 mm (0.591)	22 mm (0.866)
	75 °	3.2 mm (0.126)	12.5 mm (0.492)
	90 °	11.5 mm (0.453)	12.5 mm (0.492)
Pipe Size	min. 90A (101.6 mm or 3.5") Recommendation: bigger than 200A (216.3mm or 8")
Weight	6.5kgs
Power	1700W (or 1400W)
Inserts	3EA
	CFWB110350
Applications	Steel (carbon & stainless steel, etc.), Non-ferrous metal, other materials
